Kvant Clubmax 6500 FB4
Over the years, thousands of Clubmax FB4 lasers found their customers all around the world. Clubmax FB4 systems have a great reputation and hold their price up well. What we offer today is the 3rd generation of our all-time bestseller that we crafted to perfection. Clubmax FB4 lasers are available in the range from 3 to 40W.
The Clubmax FB4 series lasers are a radically simple solution for anything from several thousand people raves to the smallest private clubs and cosy venues. Developed with regard to challenging clubbing environments, the design is optimized to allow for long maintenance intervals and to ensure a long life span of the system as a whole.
Laser projector
Heavy-duty flight case
Mains cable
Ethernet cable
E-stop with XLR cable
Interlock [US only]
Safety keys
USB drive with manual
QC certificate
QuickShow Software
Bounce mirror - fine adjustable mount
High-quality front-coated bounce mirror for precise beam targeting.
Learn more
DiscoScan 2.0 Lens bracket
A bracket for precise fitting of Pangolin's DiscoScan 2.0 Lens.
Learn more
BEYOND License
Professional laser show design software compatiable with all KVANT lasers.
Learn more
Safety Scan Lens bracket
It's for fitting and adjusting SafetyScan lenses to all compatible KVANT lasers.
Learn more
| Source | Type: | Semiconductor laser diode | Full-colour RGB laser projector |
| Suitability: | Indoor laser displays [atmospheric, abstract, text, animations] |
| System control: | FB4-SK [Ethernet, ArtNet, DMX, ILDA | PC, Lighting Console or Autoplay] |
| Compliant with: | EN 60825-1 [tested by TÜV SÜD], FDA |
| Weight [kg]: | 11.6 |
| Size [WxHxD, mm]: | 339 x 168 x 353 [Technical Drawings are in SUPPORT section of this page] |
| Guaranteed opt. output [W]: | 6.5 |
| R | G | B [W]: | 1.36 | 2.5 | 3 [*see note A below] |
| Wavelengths [nm, ±5nm]: | 637 | 520 | 445 |
| Beam size [mm]: | 4.5 x 4.5 |
| Beam divergence [mrad]: | 0.6 [full angle, averaged value, *see note B below] |
| Modulation [kHz] | type: | 100 | analogue |
| X-Y scanners: | ScannerMAX 506 Compact | 40 Kpps @ 8° [more options in UPGRADES section of this page] |
| Power requirements [V] | Input: | 100-230/50-60Hz | Neutrik powerCON TRUE1 |
| Max. power consumption [VA]: | 340 |
| Operation temperature [°C]: | 10-40 |
| Included in the set: |
Heavy-duty flight case, 1.5M power lead, 10M Ethernet rj45 signal cable, E-STOP remote with 10M 3-pin XLR cable, set of 4 safety keys, interlock connector [for the USA only], USB memory stick with the user manual. Pangolin QuickShow laser control and creation software is available for FREE download. |
| HW features: |
All the basic system settings and adjustments such as power output adjustment for each colour, X & Y axes invert, X & Y size and position, etc. are managed via the built-in FB4 control interface. Scanning system overload protection. |
| Laser safety features: |
Keyed interlock, emission delay, magnetic interlock, scan-fail safety, fast electromechanical shutter [reaction time <20ms], adjustable aperture masking plate, Emergency STOP system with keyed remote and manual RESTART button. |
| note A | Due to Advanced Optical Correction technology used in Kvant systems, the real power output of each laser module installed within the system may slightly differ from its specification. This doesn't affect the total guaranteed power output of the system. |
| note B | The beam divergence total is calculated as an average arithmetic value of all individual colours. The divergence of each colour is calculated as: 1. FWHM of the beam cross-section for round beams, or 2. The arithmetic average of the beam's horizontal and vertical divergence for all rectangular beams. |
